| Specification | Details |
|---|---|
| SOCKET | 1151 |
| CHIPSET | Intel® Z370 Chipset |
| MEMORY CHANNEL | Dual |
| DIMM SLOTS | 4 |
| MAX MEMORY (GB) | 64 |
| PCI-E X16 | 2 |
| PCI-E GEN | Gen3 |
| PCI-E X1 | 2 |
| SATAIII | 4 |
| M.2 SLOT | 2 |
| RAID | 0/1/5/10 |
| TPM (HEADER) | 1 |
| USB 3.1 PORTS (FRONT) | 4 (Gen1, Type A) |
| USB 3.1 PORTS (REAR) | 4 (Gen1, Type A) |
| USB 2.0 PORTS (FRONT) | 4 |
| USB 2.0 PORTS (REAR) | 2 |
| AUDIO PORTS (REAR) | Realtek® ALC892 Codec |
| DISPLAYPORT | 1 |
| DVI-D | 1 |
| HDMI | 1 |
| DIRECTX | 12 |
| CROSSFIRE | Y |
| CPU SUPPORT | Support for Windows® 10 64-bit |
| FORM FACTOR | M-ATX |
